Specifications

• ENGINE

  add remove
  • Engine Type:
    V Twin
  • Cylinders:
    2
  • Engine Stroke:
    4-Stroke
  • Cooling:
    Liquid
  • Valves:
    8
  • Valves Per Cylinder:
    4
  • Valve Configuration:
    DOHC
  • Bore (in):
    3.2
  • Stroke (in):
    2.5
  • Displacement (cc):
    645
  • Fuel Injector:
    Yes
  • Carburetor:
    No
  • Carburetion Type:
    Fuel Injected
  • Bore x Stroke:
    81.0 mm x 62.6 mm (3.2 in. x 2.5 in.)
  • Compression Ratio:
    11.2:1
  • Fuel System:
    Suzuki fuel injection, SDTV-equipped
  • Lubrication:
    Wet sump
• TRANSMISSION

  add remove
  • Transmission Type:
    Manual
  • Number Of Speeds:
    6
  • Primary Drive (Rear Wheel):
    Chain
  • Reverse:
    No
  • Overdrive:
    Yes
  • Gear Ratio (1):
    2.461
  • Gear Ratio (2):
    1.777
  • Gear Ratio (3):
    1.38
  • Gear Ratio (4):
    1.125
  • Gear Ratio (5):
    0.961
  • Final Drive Ratio:
    3.133
  • Gear Ratio (6):
    0.851
  • Primary Drive (Engine / Transmission):
    Gear
• TECHNICAL SPECIFICATIONS

  add remove
  • Length (in):
    89.6
  • Width (in):
    32.9
  • Height (in):
    55.3
  • Wheelbase (in):
    61.4
  • Ground Clearance (in):
    6.7
  • Fuel Capacity (gal):
    5.3
  • Turning Radius (ft):
    8.9
  • Wet Weight (lbs):
    470
• SUSPENSION

  add remove
  • Front Suspension Type:
    Telescopic Fork
  • Front Suspension Size (in):
    1.7
  • Front Adjustable Fork Pre-Load:
    Yes
  • Front Adjustable Rebound Damping:
    No
  • Front Central Suspension Strut:
    No
  • Rear Suspension Type:
    Twin Sided Swing Arm
  • Rear Adjustable Shock / Spring Pre-Load:
    Yes
  • Rear Adjustable Rebound Damping:
    Yes
  • Number Rear Shock Absorbers:
    1
  • Rear Suspension Material:
    Aluminum
  • Front Travel (in):
    5.9
  • Rear Travel (in):
    6.3
  • Steering Damper:
    No
  • Air Adjustable:
    No
• WHEELS & TIRES

  add remove
  • Wheels Composition:
    Aluminum
  • Chromed:
    No
  • Tube / Tubeless:
    Tubeless
  • Front Tire (Full Spec):
    Bridgestone® BATTLAX Adventure 110/80 R19 59V
  • Rear Tire (Full Spec):
    Bridgestone® BATTLAX Adventure 150/70 R17 69V
  • Spare Tire:
    Not Available
• BRAKES

  add remove
  • Front Brake Type:
    Dual Hydraulic Disc
  • Rear Brake Type:
    Hydraulic Disc
  • Anti-Lock Brakes:
    Standard
  • Linked Brake System Front to Rear:
    Standard
  • Front Brake Diameter (in):
    12.2
  • Rear Brake Diameter (in):
    10.2
  • Brake Brand Name:
    Tokico®
