Specifications

• Engine & Transmission

  add remove
  • Engine Type:
    Liquid-cooled, inline 3-cylinder, 12 valve, DOHC
  • Capacity:
    798 cc
  • Bore:
    3.1 in
  • Stroke:
    2.2 in
  • Compression:
    13.2:1
  • Max Power:
    84.6 kW / 10750 rpm
  • Max Torque:
    62.0 ft-lb / 8500 rpm
  • System:
    Bosch, EFI with electronic throttle control
  • Exhaust:
    Stainless steel 3 into 1 header system with side mounted stainless steel silencer
  • Final Drive:
    X-ring chain
  • Clutch:
    Wet, multi-plate, slip and assist
  • Gearbox:
    6 speed
• Chassis

  add remove
  • Frame:
    Tubular steel perimeter frame
  • Swingarm:
    Twin-sided, fabricated steel
  • Front Wheel:
    Cast aluminium alloy 5 spoke, 17 x 3.5 in
  • Rear Wheel:
    Cast aluminium alloy 5 spoke, 17 x 5.5 in
  • Front Tyre:
    120/70 R 17
  • Rear Tyre:
    180/55 R 17
  • Front Suspension:
    Showa 41 mm Upside-down BP-SFF forks, compression and rebound damping, 120 mm wheel travel
  • Rear Suspension:
    Showa monoshock RSU, with adjustable preload and rebound damping, 130mm Wheel travel
  • Front Brake:
    Twin, 310 mm Floating discs, 4-piston radial calipers, OCABS
  • Rear Brake:
    Single, 220 mm fixed disc, single piston sliding caliper, OCABS
  • Instrument Display and Functions:
    LCD multi-function instruments with integrated colour TFT screen
• Dimensions & Weights

  add remove
  • Width Handlebars:
    32.1 in
  • Height Without Mirror:
    42.8 in
  • Seat Height:
    31.9 in
  • Wheelbase:
    55.2 in
  • Rake:
    24.5
  • Trail:
    4.3 in
  • Tank Capacity:
    3.7 gal
  • Wet Weight:
    198 kg
• Fuel Consumption

  add remove
  • Fuel Consumption:
    4.7 l/100km
