Specifications

• Engine & Transmission

  add remove
  • Engine Type:
    Liquid-cooled, 4 valve, DOHC, single-cylinder
  • Capacity:
    398.15 cc
  • Bore:
    3.5 in
  • Stroke:
    2.5 in
  • Compression:
    12:1
  • Max Power:
    29.4 kW / 8000 rpm
  • Max Torque:
    27.7 ft-lb / 6500 rpm
  • System:
    Bosch electronic fuel injection with electronic throttle control
  • Exhaust:
    Stainless twin-skin header system with stainless steel silencer
  • Final Drive:
    X-ring chain
  • Clutch:
    Wet, multi-plate, slip
  • Gearbox:
    6 speed
• Chassis

  add remove
  • Frame:
    Hybrid spine/perimeter, tubular steel, bolt-on rear subframe
  • Swingarm:
    Twin-sided, cast aluminium alloy
  • Front Wheel:
    Cast aluminium alloy 10 spoke, 19 x 2.5 in
  • Rear Wheel:
    Cast aluminium alloy 10 spoke, 17 x 3.5 in
  • Front Tyre:
    100/90 R19
  • Rear Tyre:
    140/80 R17
  • Front Suspension:
    43mm upside down Big Piston forks. 150mm wheel travel
  • Rear Suspension:
    Gas monoshock RSU with external reservoir and pre-load adjustment. 150mm wheel travel
  • Front Brake:
    320mm fixed disc, four-piston radial caliper, ABS
  • Rear Brake:
    230mm fixed disc, ByBreTM single piston floating caliper, ABS
  • Instrument Display and Functions:
    Analogue speedometer with integrated multi-function LCD screen
• Dimensions & Weights

  add remove
  • Width Handlebars:
    35.5 in
  • Height Without Mirror:
    46.0 in
  • Seat Height:
    32.9 in
  • Wheelbase:
    55.8 in
  • Rake:
    23.2 º
  • Trail:
    4.3 in
  • Tank Capacity:
    3.4 gal
  • Wet Weight:
    179 kg
• Fuel Consumption

  add remove
  • Fuel Consumption:
    3.5L/100km (80.7 mpg)
  • CO₂ Figures:
    83.8 g/km EURO 5 CO2 emissions and fuel consumption data are measured according to regulation 168/2013/EC. Figures for fuel consumption are derived from specific test conditions and are for comparative purposes only. They may not reflect real driving resu
